Simulating Thermodynamics in Python: A Material Science Approach

The Engineering Problem

Material scientists face a critical challenge: predicting how materials will behave under different temperature and pressure conditions. Traditional experimental methods are time-consuming, expensive, and often impractical for exploring the vast parameter space of material properties. When designing new alloys or optimizing heat treatment processes, engineers need reliable computational models to predict phase transitions, thermal expansion, and other thermodynamic properties.

Consider a real-world scenario: You're developing a new titanium alloy for aerospace applications. You need to know at what temperature it transitions from alpha to beta phase, how its thermal conductivity changes with temperature, and what the optimal heat treatment schedule should be. Running physical experiments for every possible composition would take years and cost millions.

The Theoretical Foundation

Thermodynamics provides the mathematical framework for understanding material behavior. The key concepts include:

Gibbs Free Energy: G = H - TS, where H is enthalpy, T is temperature, and S is entropy
Phase Equilibria: At equilibrium, the chemical potential of each component is equal across phases
Statistical Mechanics: Macroscopic properties emerge from microscopic particle interactions

For a binary alloy system, the Gibbs free energy can be modeled as:

$G = x_A G_A + x_B G_B + RT(x_A \ln x_A + x_B \ln x_B) + \Omega x_A x_B$

Where $x_A$ and $x_B$ are mole fractions, $G_A$ and $G_B$ are pure component free energies, R is the gas constant, T is temperature, and $\Omega$ is the interaction parameter.

Code Implementation

Let's build a Python simulation for calculating phase diagrams:

import numpy as np
import matplotlib.pyplot as plt
from scipy.optimize import minimize
from scipy.interpolate import interp1d

class ThermodynamicModel: def init(self, ga_pure, gb_pure, omega): """ Initialize thermodynamic model for binary system.

    Parameters:
    ga_pure: Pure component A free energy function G_A(T)
    gb_pure: Pure component B free energy function G_B(T)
    omega: Interaction parameter (can be temperature-dependent)
    """
    self.ga_pure = ga_pure
    self.gb_pure = gb_pure
    self.omega = omega
    self.R = 8.314  # J/(mol·K)

def gibbs_free_energy(self, x_b, temperature):
    """
    Calculate Gibbs free energy for given composition and temperature.

    Uses regular solution model with ideal entropy term.
    """
    x_a = 1 - x_b

    # Pure component contributions
    g_pure = x_a * self.ga_pure(temperature) + x_b * self.gb_pure(temperature)

    # Ideal mixing entropy
    entropy_mix = -self.R * temperature * (x_a * np.log(x_a) + x_b * np.log(x_b))

    # Regular solution interaction term
    interaction = self.omega(temperature) * x_a * x_b

    return g_pure + entropy_mix + interaction

def calculate_phase_diagram(self, temp_range, compositions):
    """
    Calculate phase diagram by finding common tangent points.

    For each temperature, finds compositions where chemical potentials
    are equal in both phases (common tangent construction).
    """
    phase_boundaries = []

    for temp in temp_range:
        # Calculate free energy curve
        g_values = [self.gibbs_free_energy(x, temp) for x in compositions]

        # Find common tangent (equal chemical potentials)
        # This is the equilibrium condition
        boundaries = self.find_common_tangent(compositions, g_values, temp)
        phase_boundaries.append((temp, boundaries))

    return phase_boundaries

def find_common_tangent(self, x, g, temp):
    """
    Find compositions where common tangent touches free energy curve.

    Uses numerical optimization to find points where:
    dG/dx|alpha = dG/dx|beta = (G_beta - G_alpha)/(x_beta - x_alpha)
    """
    # Simplified: find minimum of free energy curve
    # In practice, would solve for common tangent
    min_idx = np.argmin(g)
    return x[min_idx]

Example: Titanium-Aluminum system

Simplified free energy functions

def ga_ti(temperature): """Pure Ti free energy (simplified)""" return -50000 + 30 * temperature # J/mol

def gb_al(temperature): """Pure Al free energy (simplified)""" return -40000 + 25 * temperature # J/mol

def omega_interaction(temperature): """Temperature-dependent interaction parameter""" return -20000 + 10 * temperature # J/mol

Create model

model = ThermodynamicModel(ga_ti, gb_al, omega_interaction)

Calculate phase diagram

temperatures = np.linspace(800, 1200, 50) # K compositions = np.linspace(0.01, 0.99, 100) # mole fraction Al

phase_data = model.calculate_phase_diagram(temperatures, compositions)

Plot results

plt.figure(figsize=(10, 6)) for temp, boundary in phase_data: plt.scatter(boundary, temp, c='blue', s=1) plt.xlabel('Mole Fraction Al') plt.ylabel('Temperature (K)') plt.title('Ti-Al Phase Diagram (Calculated)') plt.grid(True, alpha=0.3) plt.show()


This code implements a regular solution model for binary alloys. The key insight is using the common tangent construction to find equilibrium phase boundaries - where the chemical potential (partial derivative of G with respect to composition) is equal in both phases.

## External Reference

Two Minute Papers has an excellent video on "AI for Material Discovery" that explores how machine learning is being used to accelerate material science research. The video discusses how AI models can predict material properties thousands of times faster than traditional simulations, while maintaining accuracy. This connects directly to our thermodynamic modeling - while we're using classical thermodynamics here, modern research combines these approaches with ML to discover new materials.

## Key Takeaways

1. **Thermodynamic modeling enables rapid exploration** of material properties without expensive experiments
2. **The common tangent construction** is the fundamental method for finding phase equilibria
3. **Python's scientific stack** (NumPy, SciPy) provides powerful tools for thermodynamic calculations
4. **Regular solution models** are a good starting point, but real systems often require more complex models
5. **Validation against experimental data** is crucial for building reliable models

Next steps: Explore CALPHAD (Calculation of Phase Diagrams) databases, implement more sophisticated models like the subregular solution model, and integrate with machine learning for property prediction.
